Humminbird HELIX 10 Fish Finder with GPS, CHIRP Sonar & Basemap

Advanced Sonar, GPS Mapping & Network Connectivity for Confident Fishing

Take your time on the water to the next level with the Humminbird HELIX 10, a powerful fish finder designed to provide detailed sonar imaging, GPS navigation, mapping, and advanced networking capabilities. Featuring a large 10-inch color TFT display, intuitive keypad controls, Dual Spectrum CHIRP sonar, internal GPS, and an enhanced Humminbird Basemap, the HELIX 10 gives anglers a clear view of fish, structure, bottom conditions, and surrounding waterways.

Built for serious anglers, the HELIX 10 also supports AutoChart Live, premium mapping options, Ethernet networking, Bluetooth, NMEA 2000 connectivity, and the One-Boat Network. Whether you’re locating fish, mapping underwater terrain, or integrating multiple marine electronics, this system is designed to provide a comprehensive view of what’s happening beneath and around your boat.

Key Features

Large 10-Inch Color Display

The HELIX 10 features a large, easy-to-view display designed to provide clear access to sonar, GPS, mapping, and navigation information.

• 10-inch screen
• Color TFT display
• Designed for clear viewing of sonar and mapping data
• User-friendly interface
• Keypad-based operation

Keypad Control

Master the HELIX through a straightforward button-based control system.

• Convenient keypad operation
• Softkey controls
• Easy access to pre-loaded views
• User-friendly menu system
• Designed for reliable operation in varying conditions

Dual Spectrum CHIRP Sonar

See what’s beneath your boat with detailed sonar information designed to help identify fish and underwater structure.

• Dual Spectrum CHIRP 2D sonar
• Detailed fish arches
• Clear view of fish-holding structure
• Clear bottom detail
• Powered by Humminbird’s proprietary Low-Q CHIRP transducer
• Two search modes:
  • Wide Mode for maximum coverage
  • Narrow Mode for increased detail

Internal GPS & Humminbird Basemap

Navigate with built-in GPS and detailed mapping information.

The enhanced Humminbird Basemap provides information about underwater terrain and surrounding points of interest.

Identify features such as:

• Buoys
• Day markers
• Hazards
• Marinas
• Contours
• Depth markers
• Underwater terrain
• Points of interest

The included basemap contains charts covering more than 10,000 lakes, along with coastal coverage for the continental United States.

Premium Chart Compatibility

Expand your mapping capabilities with compatible premium chart options.

The HELIX 10 supports optional chart products including:

• Humminbird LakeMaster
• Humminbird CoastMaster
• Compatible Navionics charts

AutoChart Live

Create detailed maps of your fishing locations in real time as you operate your boat.

AutoChart Live allows you to map:

• Depth contours
• Bottom hardness
• Vegetation

The system includes 8 hours of built-in recording time and supports AutoChart Zero Line SD cards for virtually unlimited AutoChart Live mapping capacity.

One-Boat Network Compatibility

Integrate your HELIX 10 with compatible Humminbird and Minn Kota products through the One-Boat Network.

This connectivity can help unlock additional boat-control and fishing features while allowing compatible marine electronics to communicate as part of an integrated system.

Ethernet Networking

High-speed Ethernet networking allows you to build a professional-grade marine electronics system.

• Connect multiple compatible fish finders
• High-speed networking
• Expandable system architecture
• Compatible with add-on technologies such as:
  • Minn Kota i-Pilot Link
  • Humminbird CHIRP Radar

Bluetooth Connectivity

Built-in Bluetooth provides wireless communication with compatible accessories and mobile devices.

Features include:

• Wireless communication with compatible Talon shallow-water anchors
• Wireless communication with compatible Raptor shallow-water anchors
• Wireless software updates through the Humminbird FishSmart App
• Smartphone notification display on the HELIX

Built-In NMEA 2000 Networking

Connect an accessory NMEA 2000 network to the control head to access additional marine information.

NMEA 2000 connectivity can help integrate information relating to:

• Boat performance
• Weather conditions
• Water conditions
• Other compatible marine system data

Sonar & Navigation

Display & Controls

Connectivity & Networking

Power

Mapping & Charting

The HELIX 10 provides a versatile mapping platform for anglers who want to navigate waterways while identifying productive fishing areas.

Included Humminbird Basemap

• More than 10,000 lakes
• Continental U.S. coastal coverage
• Underwater contours
• Depth markers
• Buoys
• Day markers
• Hazards
• Marinas
• Points of interest

Optional Premium Mapping

The unit is compatible with optional:

• Humminbird LakeMaster charts
• Humminbird CoastMaster charts
• Compatible Navionics charts
• AutoChart Zero Line SD cards

AutoChart Live Mapping

Use AutoChart Live to build real-time maps while moving across the water.

The system can record and display:

• Depth contours
• Bottom hardness
• Vegetation

The unit includes 8 hours of built-in AutoChart Live recording capacity, with support for AutoChart Zero Line SD cards to greatly expand mapping capacity.

What’s in the Box

• Humminbird HELIX 10 control head
• Transom-mount transducer
• Power cable
• Gimbal mounting bracket
• Mounting hardware

Warranty

The Humminbird HELIX 10 is backed by a:

• 1-Year Limited Warranty

Ideal Applications

The HELIX 10 is designed for anglers who want advanced sonar, navigation, mapping, and marine-system connectivity.

Ideal for:

• Freshwater fishing
• Coastal fishing
• Recreational boating
• Serious anglers
• Fishing tournaments
• Boat navigation
• Fish and structure identification
• Underwater mapping
• Integrated marine electronics systems

Why Choose the Humminbird HELIX 10?

The Humminbird HELIX 10 combines a large 10-inch color display with Dual Spectrum CHIRP sonar, internal GPS, detailed Humminbird Basemap mapping, AutoChart Live, Bluetooth, Ethernet, and built-in NMEA 2000 networking. Its compatibility with the One-Boat Network and premium charting solutions also provides a foundation for expanding your boat’s electronics system.

From identifying detailed fish arches and underwater structure to creating real-time depth maps and integrating compatible marine equipment, the HELIX 10 is designed to give anglers more information and control while they’re on the water.

Mapping coverage, compatible accessories, chart availability, networking functionality, and software features may vary by region, compatible equipment, and software version. Optional charts and accessories may be sold separately.
