The New Vector 500 Camo Utility Vehicle brings true powersports performance to a versatile off-road platform. Powered by a 471cc fuel-injected four-stroke engine producing an estimated 20 HP, the Vector 500 can reach a listed maximum forward speed of 45 mph.

Built for hunting, work, and off-road adventures, the Vector 500 Camo features on-demand four-wheel drive with a front differential lock, Hi/Lo range automatic CVT transmission, large 26-inch tires, and shaft-driven 4WD. Its race-inspired Level Flight Suspension system with nitrogen-assisted shocks is designed to provide controlled performance over uneven terrain.

Standard equipment includes a 3,500 lb. winch, removable two-piece windshield, roof, headlights, tail lights, turn signals, mirrors, fender flares, headrests, and front bumper, giving the Vector 500 a comprehensive utility package straight from the factory.

Key Features

471cc Fuel-Injected Engine

The Vector 500 is powered by a 471cc gasoline engine designed to deliver strong off-road performance.

• 471cc fuel-injected four-stroke engine
• Estimated 20 HP
• Maximum listed torque: 16.15 ft-lb
• Gasoline fuel
• 7.6-gallon fuel tank
• OEM-branded engine

Automatic Hi/Lo CVT Transmission

The automatic CVT provides convenient operation while the selectable Hi/Lo range allows the drivetrain to be configured for different riding and utility conditions.

• Automatic CVT transmission
• High/Low range
• Designed for work and off-road applications

On-Demand 4-Wheel Drive

The Vector 500 provides selectable traction through its on-demand 4WD system.

• On-demand 4-wheel drive
• Front differential lock
• Shaft-driven 4WD system
• 10-inch ground clearance

Level Flight Suspension

A race-inspired Level Flight Suspension system combines independent suspension components with nitrogen-assisted shocks to help the vehicle maintain controlled handling over uneven terrain.

• Independent 4-wheel dual A-arm suspension
• Nitrogen-assisted shocks
• Level Flight Suspension system
• 10-inch ground clearance

26-Inch All-Terrain Tires

Large 26-inch tires provide the ground contact needed for outdoor trails, hunting areas, and off-road work.

• 26-inch tires
• Independent 4-wheel suspension
• 10-inch ground clearance

Four-Wheel Hydraulic Disc Brakes

Hydraulic disc brakes on all four wheels provide controlled braking performance for a utility vehicle capable of reaching up to 45 mph.

• 4-wheel hydraulic disc brakes
• Designed for off-road use

Standard Winch & Utility Equipment

The Vector 500 Camo comes equipped with a substantial range of standard accessories.

• 3,500 lb. winch
• Front bumper
• Fender flares
• Mirrors
• Headrests
• Cup holder
• 2-piece removable windshield
• Roof
• On-road light package

Cargo & Towing Capability

The Vector 500 is designed to handle both passengers and utility equipment.

• 2-person seating capacity
• 8.3 cu. ft. cargo bed capacity
• Tilting cargo bed
• 500 lb. load weight capacity
• 3,500 lb. listed towing capacity

Specifications

Engine & Performance

Suspension, Brakes & Tires

Dimensions & Capacity

Standard Equipment

Utility & Off-Road Applications

The Vector 500 Camo is designed for a variety of outdoor and utility applications, including:

• Hunting
• Off-road adventures
• Trail riding
• Property maintenance
• Outdoor work
• Utility transportation
• Recreational riding

Camo Finish & Outdoor Design

Finished in a Camo color scheme, the Vector 500 is styled for outdoor environments and utility-focused use. The roof, removable windshield, mirrors, fender flares, lighting package, and front bumper provide a practical configuration for extended outdoor operation.

Warranty

The Vector 500 Camo comes with a 2-year manufacturer warranty.

Why Choose the Vector 500 Camo?

The Vector 500 Camo Utility Vehicle combines a 471cc fuel-injected engine, automatic Hi/Lo CVT, on-demand 4WD with front differential lock, independent dual A-arm suspension, nitrogen-assisted shocks, and four-wheel hydraulic disc brakes into a capable off-road platform.

With a 3,500 lb. winch, 3,500 lb. listed towing capacity, tilting cargo bed, 500 lb. load capacity, 7.6-gallon fuel tank, 26-inch tires, roof, removable windshield, and complete lighting package, the Vector 500 is equipped for hunting, work, and recreational off-road use right from the factory.
